Single cylinder air cooled
Bore 65 mm
Stroke 52 mm
Total displacement 172.5 cc
Compression ratio 11:1
Fuel delivery to the crankcase: four blade reed-valve system connected to the crankcase
Diaphragm carburetor WB37
Reducer with Poly V belt available in 1:2,2, 1: 2,3, 1: 2.5, 1: 2,6, 1: 2.7, 1: 2.88
Continuous operating temperature 180° C, maximum temperature 240° C
Engine mounting: by 5 shock absorbing rubber mounts
Propeller rotation: counterclockwise
Maximum RPM 7900 RPM
Spark plug NGK B9ES – NGK B9ERS – DENSO W27ESR-U
Manual starter included
Crankcases molten in G-Al Si 9 UNI 3051 alloy subsequently treated
Six port distribution system
Cylinder in light silicon alloy with Cermetal protective coating
Piston with ultra-light structure reinforced with side flaps for heat dispersion. Flaps in 2 segments, 1.2 mm S10 chrome-plated semi trapezoidal cast iron.
Head in die cast aluminum alloy with high percentage of silicon and concentric combustion chamber, calculated squish
Drive shaft in 18 Ni Cr Mo5 with 5 thermic treatments on every component
Connecting rod in copper plated steel 18Ni Cr Mo 5 joined to the drive shaft through very precise high speed silver-plated roller bearings
Roller bearings fit for high speed class C3
Seal ring in Witon with very high resistance and long duration
OPTIONS OF ENGINE, PLEASE SPECIFY WHEN BUY IT.
- Hand Start
- Electric Starter
- Hand Start & Centrifugal Clutch
