Vittorazi Moster Factory MY22

The creative energy of Vittorazi Motors, combined with the passion and professional commitment have led to the birth of the Moster 185 Factory, the top of the range, destined to become the new extreme point of reference of the engines for the flight.

Every detail, even the smallest, is the result of innovative engineering solutions. Airbox in carbon fiber, new ignition “Selettra”, titanium screws, iridium spark plug, for a seemingly impossible goal to achieve but brilliantly centered: the incredible weight of only 12.5kg for a displacement of 185cc.

👉We BEAT any offer on the market. Bring your quote and we will match or improve it. Guaranteed💪.

Description

We match the price of the competition … Call us for Quote… (787)717-2384.

Distinctive design, racing look, for a model that strengthens the quality and reliability of the already known Moster185.

It is the perfect model for those who require, at the same time, a lightweight and gritty engine, faithful to best Vittorazi tradition, together with an exciting engine to use both in competitions and in pleasure flights.

For this new version, it has been studied a new engine case in aluminum 7075, machined from solid, whose mass has been reduced by 10% improving, at the same time, the heat exchange capacity and the endurance.
In addition to the engine case, the new Moster 185 Factory cylinder, offers a further increase of the heat exchange along with an improvement in performance, resulting from advanced studies on fluid dynamics. Also in this case the mass is decreased by 10% as well as have decreased the acoustic emissions. Both components have been the subject of a restyling that have made them, moreover, very appealing from an aesthetic point of view.

Every detail, even the smallest, is the result of innovative engineering solutions. Air-box in carbon fiber, new ignition “Selettra”, titanium screws, iridium spark plug, for a seemingly impossible goal to achieve but brilliantly centered: the incredible weight of only 12.5kg for a displacement of 185cc.

👉We BEAT any offer on the market. Bring your quote and we will match or improve it. Guaranteed💪.

Cycle 2 strokes
Stroke 54 mms
Swept volume 184.7 cc
Bore Ø 66 mms
Power 25 hp at 7.800 rpm
Cylinder Single cylinder in aluminum Nicasil chromed
Piston HQ diamond profile, graphite coating, 2 rings chromed
Intake Carbon air-box silencer – Walbro carburetor – Reed valve intake
Cooling Extraction from propeller
Starter Manual pull start – 3S (Soft Starter System)
Clutch Centrifugal clutch
Reduction drive ratio 1/2.68 – 1/2.87 – PolyV belt.
Ignition coil Inductive IDI
Spark-plug Iridium NGK EIX
Temperatures max
EGT 550° – CHT 250°
Exhaust pipe TITANIUM hand made muffler with carbon silencer
Propeller rotation Anticlockwise
Fuel Unleaded gasoline – Synthetic oil 2.5 %
Consumption 3.8 – 4.2 liters/hour at 30kg of static thrust, propeller 125cms at 5600 RPM
Weight 12.5 kg; pull starter version
Weight N/A electric starter version
Weight N/A pull & electric starter version
