Description
Accessible High Performance
The latest generation of the Viper series is the most accessible high performance PPG wing we have flown. It contains all of the World Championship winning speed, agility and performance of the Viper 5, with significantly improved comfort and ease of use.
The Viper XC is a fast, efficient, and fun to fly wing that balances comfort and performance for the advanced pilot. With easier launch and landing characteristics, improved roll stability, and the same incredible top speed of the Viper 5, this is an exciting wing for expedition and adventure flying.
Tech
The Viper 5 and Viper XC share the same cell count, profile, aspect ratio, and low-drag line plan. The Viper XC’s riser lines are sheathed for ease of use. Proven in countless PPG competitions including the World Championships, the Ozone reflex profile remains solid throughout the speed range and accepts low angles of attack, enabling a very high top speed.
The Viper XC features winglets for increased roll and spiral stability, making the wing easier to control, more efficient and more comfortable in flight. Their positive effect can be immediately felt regardless of wing loading, motor type, or style of flight. The increased roll stability is ideal for XC adventure at high speeds.
Risers
The dedicated Viper XC riser system is available in two versions. The standard risers are suitable for the majority of pilots and are shorter, simpler, and easier to use than the PK risers. The standard risers offer long range trimmers, fully adjustable brake pulley heights, neoprene brake handles and strong magnet clips. The PK risers are for pilots who want the direct action of the PK system for faster acceleration. Both risers feature the 2D steering system for efficient high-speed control.
Pilot
This is an advanced wing designed for experienced pilots. It is suitable for those who want to step up from the Speedster or Sirocco to a more comfortable and less demanding wing than the Viper 5 or Freeride. The Viper XC’s characteristics make it an ideal wing for the discerning advanced pilot who appreciates dynamic handling, but still wants efficiency and XC performance with high level of cruise stability.
Specifications
| Sizes | 16 | 18 | 20 | 22 | 24 |
|---|---|---|---|---|---|
| Number of cells | 62 | 62 | 62 | 62 | 62 |
| Projected area (m2) | 13.7 | 15.4 | 17.1 | 18.8 | 20.5 |
| Flat Area (m^2) | 16.1 | 18.1 | 20.1 | 22.1 | 24.1 |
| Projected Span (m) | 7.68 | 8.15 | 8.58 | 9 | 9.4 |
| Flat Span (m) | 9.64 | 10.22 | 10.77 | 11.3 | 11.8 |
| Projected Aspect Ratio | 4.3 | 4.3 | 4.3 | 4.3 | 4.3 |
| Flat Aspect Ratio | 5.8 | 5.8 | 5.8 | 5.8 | 5.8 |
| Root Chord (m) | 2.1 | 2.23 | 2.35 | 2.46 | 2.57 |
| Glider Weight (kg) | 4.09 | 4.45 | 4.76 | 5.06 | 5.42 |
| PG Weight Range (kg) | 55-80 | 65-90 | 75-105 | 85-115 | 95-125 |
| PPG Weight Range (kg) | 80-110 | 90-120 | 100-135 | 110-145 | 115-160 |
| DGAC | DGAC | DGAC | DGAC | DGAC | DGAC |
* Weights may vary up to 50gm per size due to slight variations in the manufacturing of the fabric used.
Materials
- Top Surface Cloth: Dominico 30D
- Bottom Surface Cloth: Dominico N20D
- Rib cloth: Porcher 901 E29 (hard)
- Upper lines: Edelrid 8001 series
- Mid lines: Edelrid 8001 series
- Lower Lines: Edelrid 7343 series
Package Contents
Your OZONE wing is delivered standard with the following accessories:
Inner Bag, Glider Strap, Riser bag, Speed Bar, OZONE Stickers, Repair Cloth, OZONE Keyring.
You may choose to add something to your order, such as: Easy Bag (stuff bag), Light Easy bag (video), Saucisse Bag (video) (concertina packing bag), Glider Backpack, or OZONE Clothing and Accessories.
