Vittorazi Atom80

The ATOM80 is perfect for anyone who appreciates a lightweight engine, delivering power with economy and low noise.

The ATOM is a light quiet engine (10.5 Kg), well balanced, easy to start with ‘Ultrasoft’, and packs a punch (16 Hp @ 9500 rpm) with low fuel consumption.

Forced air cooled engine,  oil bathed helical gear reduction drive, with a centrifugal adjustable clutch.

The thrust is smooth, linear delivering 55kg with a 130 cm propeller and 52kg with 125 cm propeller.

👉We BEAT any offer on the market. Bring your quote and we will match or improve it. Guaranteed💪.

Description

We match the price of the competition … Call us for Quote… (787)717-2384.

Cycle2 strokes
Stroke44 mms
Swept volume78.2 cc
BoreØ 47.6 mms
Power16 hp at 9.500 rpm
CylinderSingle cylinder in aluminum Nicasil chromed
PistonDiamond profile, 1 chromed piston ring
IntakeSilencer airbox – Walbro carburetor WG8 with choke system
Reed valve intake

CoolingForced air ventilation system with fan and conveyer
StarterPull starter
ClutchAdjustable centrifugal
Reduction driveOil lubricated helicoidal gearings – Ratio 1/3.6 – 1/3.8
Ignition coilInductive IDI
Spark-plugNGK BR9ES
Temperatures
EGT 550° – CHT 150°
Exhaust pipeHand-made with resonator and db killer chamber
Propeller rotationClockwise
FuelUnleaded gasoline – Synthetic oil 1.5%
Consumption2.70-3.20 liters/hour at 30kgs of static thrust, prop.125cms at 8.000 RPM
Weight10.5 kg
Max Trust55kgs prop. 130cms at 9.800RPM

52kgs prop. 125cms at 9.800RPM

👉We BEAT any offer on the market. Bring your quote and we will match or improve it. Guaranteed💪.
